Arctic F14 PWM standard case fan with PWM Retail Box 1 Year warranty
Alternate Description
Arctic F14 PWM Case Fan, 140mm Fan, 550 ~ 1,350 RPM, 77.3 CFM, 24.4 dBA, 0.16A Current,12V
Product Overview
The Arctic F14 PWM forward the PWM signal from the CPU to the whole case ventilation system that offers a perfect mix of performance and durability.
This 140mm fan takes care that heat emitted in the course of operation is dissipated effectively. The blade spins at 550 - 1,350 RPM with 77.3 CFM to produce high pressure airflow. With 0.5 Sone Noise Level, it allows a silent work environment and uses just 12V to run conserving energy.
Sporting a standard 25mm frame, this PWM Case Fan can be used as intake or outtake system fan. It features a fluid dynamic bearing and comes in a patented fan holder design that not only guarantees an ultra-quiet operation, but also boasts of durability.
The entire system is cooled quietly, but still offers the superb performance when needed Via the PWM signal, the CPU fan is controlled by the main board to reach the ideal temperature for the CPU. The patented PST (PWM Sharing Technology) is forwarding the PWM signal to all other fans inside the system. This way, all fans are spinning at the same speed. This provides silent operation in idle mode, but also gives sufficient performance, when required to offer efficient cooling.
Features
• Patented PWM Sharing Technology (PST)
• Extremely quiet with low noise impeller
• High airflow and static pressure
• Fluid dynamic bearing ensures extended lifespan
Specifications
• Fan Type: Case Fan
• Fan Size: 140mm
• Bearing Type: Fluid Dynamic Bearing
• RPM 550 ~ 1350 RPM (controlled by PWM)*
• Air Flow 77.3 CFM / 131.4 m /h
• Noise Level: 24.4 dBA (0.5 Sone)
• Voltage:6-12 V
• Current:0.16A
• Heat sink Dimensions: 140 (L) x 140 (W) x 25 (H) mm
